Multi-cavity pen mold injection molding process, processing design and manufacturing

Views: 0     Author: Site Editor     Publish Time: 2024-03-12      Origin: Site

Multi-cavity pen mold injection molding process, processing design and manufacturing

With the advancement of material science, the material selection of pen molds is becoming more and more abundant. New high-strength, wear-resistant, and high-temperature resistant materials have been continuously developed, which has significantly improved the service life and performance of pen molds. From a design point of view, the design of pen molds pays more and more attention to precision and detail. With the popularity of computer-aided design (CAD) and computer-aided manufacturing (CAM) technologies, designers are able to simulate and optimize mold designs more accurately, reduce the number of trial and error, and improve production efficiency. The progress of manufacturing technology has also provided strong support for the development of pen molds. The application of advanced technologies such as high-precision CNC machine tools, laser cutting, and EDM has greatly improved the manufacturing accuracy and efficiency of pen molds. At the same time, the introduction of automatio


In the design and manufacturing process of pen molds, the following points are particularly important:

1. Design: When designing a pen mold, the first thing to consider is the shape and size of the product. Designers need to accurately calculate the size and structure of the mold according to the needs of the product. In addition, designers also need to consider factors such as the strength, wear resistance, and corrosion resistance of the mold to ensure that the mold can maintain stability and durability during use.

2. Material selection: The choice of material directly affects the quality and service life of the pen mold. Generally speaking, materials with moderate hardness, good toughness, wear resistance, and high temperature resistance should be selected. Such materials can better resist thermal pressure and impact forces during the mold making process, and prolong the service life of the mold.


3. Machining accuracy: The machining accuracy of the pen mold has an important impact on the quality and production efficiency of the product. Therefore, in the manufacturing process, high-precision processing equipment and processes need to be used to ensure that the various parts of the mold can be accurately matched and reduce errors.

4. Assembly and debugging: Assembly is an important part of the mold making process. During the assembly process, it is necessary to ensure that the individual components fit together accurately to avoid problems such as gaps or misalignment. At the same time, it is also necessary to debug the mold to ensure that it can run stably in the production process and achieve the expected production results.


Dongguan Fanshida Intelligent Technology Co., Ltd. is a company with professional ability and rich experience in the field of pen opening injection molding, and its product quality and technical level are in the leading position in the industry. Pay attention to technological innovation and R&D investment, and constantly introduce advanced production equipment and technical means to improve production efficiency and product quality. The company also has an experienced and skilled R&D team, which can continuously launch competitive new products according to market demand and customer needs.
